Armstrong Whitworth Awana
1923
Back to the Virtual Aircraft Museum
  Virtual Aircraft Museum / United Kingdom / Armstrong Whitworth

Armstrong Whitworth Awana

There is no text information for this aircraft at the moment.

Armstrong Whitworth Awana


Specification
 ENGINE2 x 450hp Napier Lion
 WEIGHTS
    Take-off weight8373 kg18459 lb
    Empty weight4536 kg10000 lb
 DIMENSIONS
    Wingspan32.16 m106 ft 6 in
    Length20.72 m68 ft 0 in
    Height6.17 m20 ft 3 in
    Wing area213.68 m22300.03 sq ft
 PERFORMANCE
    Max. speed156 km/h97 mph
    Ceiling2438 m8000 ft
    Range579 km360 miles

3-View
Armstrong Whitworth AwanaA three-view drawing (800 x 791)

Comments
Barry, 15.06.2016

Built to Air Ministry Spec. 5/20, only two of these troop carriers were built. Designed to carry 25 troops over 400 miles and to be capable of rough ground take off and landing and also to have the ability to fly on one engine, the prototype was found to be flimsy and difficult whilst landing. The second prototype addressed some of the concerns, but it was decided to order the Vickers Victoria instead.

, 20.06.2011

Armstrong Whitworth Awana
1923
