Armstrong Whitworth F.K.9

The F.K.9 two-seat fighter-reconnaissance quadruplane was built by Sir W G Armstrong Whitworth & Co Ltd as a private venture, and was initially flown in the summer of 1916. Initial trials dictated a number of modifications, including new wings with enlarged ailerons, an enlarged fin, a redesigned engine cowling and increased undercarriage track. In this form, powered by a 110hp Clerget 9Z rotary engine, and with a designated armament of one fixed 7.7mm Vickers gun and one free 7.7mm Lewis gun, the F.K.9 was officially tested in November-December 1916 at the Central Flying School. A production contract for 50 examples of an improved version, the F.K.10, was awarded.


Specification
 WEIGHTS
    Take-off weight924 kg2037 lb
    Empty weight556 kg1226 lb
 DIMENSIONS
    Wingspan8.46 m28 ft 9 in
    Length7.87 m26 ft 10 in
    Height3.45 m11 ft 4 in
    Wing area32.98 m2354.99 sq ft
 PERFORMANCE
    Max. speed151 km/h94 mph
