The prototype Dart-engined Herald made its first flight on 11 March 1958 and the first production Herald Series 100 flew on 30 October 1959. The Series 100 accommodated between 38 and 47 passengers. The Series 200 was the main production version with a forward fuselage 1.07m longer than that of the Series 100. Accommodation was provided for 50-56 passengers.
The Series 300 (a modified Series 200 developed to meet US airworthiness requirements) was followed by the Series 400 military transport with a side loading door and accommodation for 50 troops, paratroops, 24 stretchers or freight, eight of which went to the Royal Malaysian Air Force. The projected Series 500 was followed by the Dart 532/9 turboprop-engined Series 600.
The final two versions were the Series 700 long-range version of the Series 600, accommodating up to 60 passengers or 52 passengers and baggage over 1,980km stages, and the Series 800 military version of the 700.
| MODEL | Herald Series 200 |
| CREW | 2 |
| PASSENGERS | 50-56 |
| ENGINE | 2 x Rolls-Royce Dart 527 turbo-props, 1570kW |
| WEIGHTS |
| Take-off weight | 19504 kg | 42999 lb |
| Loaded weight | 11703 kg | 25801 lb |
| DIMENSIONS |
| Wingspan | 28.88 m | 95 ft 9 in |
| Length | 23.01 m | 76 ft 6 in |
| Height | 7.34 m | 24 ft 1 in |
| Wing area | 82.31 m2 | 885.98 sq ft |
| PERFORMANCE |
| Max. speed | 495 km/h | 308 mph |
| Cruise speed | 445 km/h | 277 mph |
| Ceiling | 8500 m | 27900 ft |
| Range w/max.payload | 1786 km | 1110 miles |
| Pete Simpson, petehsimpson12=yahoo.co.uk, 10.06.2012 Hi, I helped make the navigation tables for the Malasian Heralds while I was an apprentice at Cricklewood | | Neil, munroav=aol.com, 21.08.2011 I flew the Herald in the mid 1970's for 1200 hours. I thought is was very pleasant to fly. Strong and had good handling feel compared to the DC3 which felt that the ailerons were attached with glue. During training we would go to a strip of land just south of Jersey which at low tide looked like a runway. Bad weather circuits at 200 feet were good fun, let us see what the aircraft could do and increased our confidence. Passengers seemed to like it as well. | | Barry, 21.02.2011 The RAF originally selected this as a transport in preference to the Avro (HS)748. However, because Sir Frederick Handley Page would not unite his company with either Hawker Siddley or BAC the goverment decided to "punish" him by not awarding his company any contracts. So that was really the writing on the wall for this once great company and eventually it disappeared altogether. It really is good the way politicians support industry in this country isn't it? | | luiz cauduro, luizcaudurocdr=gmail, 14.09.2010 sou aeronauta e este equipamento fez parte da minha infacia. voei muito pela Sadia quando menino.unica cia.brasileira que operava este equipamento. | | Ken Watkins, braynord=orange.fr, 25.06.2007 Congratulations on your excellent website, which I've just discovered today!
From 1954 to 1955 I worked as a stressman for Handley Page (Reading) on the wing of the Herald. You might like to add to the history of this aircraft that it was conceived as a Dakota replacement (as was its competitor the Fokker Friendship). Initially it was to have four Alvis Leonides engines, but Rolls-Royce developed the Dart (for the Vickers Viscount) so successfully that the design became the one you show. |
|
