Hawker Siddeley Hunter
1951
Back to the Virtual Aircraft Museum
  FIGHTER, ATTACK, RECONVirtual Aircraft Museum / United Kingdom / Hawker

Hawker Siddeley Hunter

See also: Damien Burke's Page

3-View
Hawker Siddeley HunterA three-view drawing (1663 x 1187)


Specification
 CREW1-2
 ENGINE1 x Rolls-Royce "Avon" RA 28, 44.1kN
 WEIGHTS
    Take-off weight10885 kg23997 lb
    Empty weight6020 kg13272 lb
 DIMENSIONS
    Wingspan10.2 m33 ft 6 in
    Length14.9 m49 ft 11 in
    Height4.3 m14 ft 1 in
    Wing area32.4 m2348.75 sq ft
 PERFORMANCE
    Max. speed1150 km/h715 mph
    Ceiling16760 m55000 ft
    Range w/max.fuel2900 km1802 miles
    Range w/max.payload900 km559 miles
 ARMAMENT4 x 30mm cannons, bombs and missiles

Hawker Siddeley Hunter

Comments
Minnie, mnnovens\"yahoo.com, 21.08.2010

Apparently so smooth that Ian Dick of 20 Sqn did a "roller", at 300 knots off a thick patch of trees, having mis-estimated his sink rate after rocket fire.
Climbed to 5000 ft under power at which time engine flamed out and he then ejected.

Bob Palman, ballykelly-shack=hotmail.com, 04.08.2010

# 111 Sqdn RAF Fighter Command. The Black Arrows. At Farnborough, 22 black Hunters looping and rolling. Has anybody else ever tried to do that? you always see the Blue Angles and the Thunderbirds looping and rolling six and seven aircraft, but twentytwo, hey, there you go.

paul scott, psmiddx=yahoo.com, 20.08.2009

Despite Britain's technological prowess in terms of jet propulsion/design, we never really adopted the swept wing for in-service fighters quickly enough compared to both the USA and Russia (Sure, plenty in experimental types, but as I say, late on in-service fighters). So much so, the American lead with the excellent Sabre, the British pilots didn't want to trade their Sabres in for the Hunter, until they flew it. Although in service against faster types (Iraqi hunters managed to shoot down four Israeli Mirage III's due to the latter's low-level and turn deficiencies with the Delta wing)it still excelled in service and was a graceful, classic design. Once the bugs were ironed out that is. Churchill rushed it into priorty production where the bugs showed, but nevertheless, perhaps the most successful British aircraft.

Jock Williams, williamsB25=aol.com, 19.04.2009

I only ever flew the dual model -and it was after I had flown the F104 for several years so naturally it didn't compare in absolute speed or climb rate, but it was just a wonderful machine to fly -very smooth and responsive on the controls and extremely manoeuverable!
I think the Hunter and the Sabre are as much classics of their era as were the Hurricane, Spitfire and Mustang.
And THAT -is saying something!

Jock Williams Yogi 13

J A Chesters, wojac=hotmail.com, 27.01.2009

Mk 4 was a dream you could fix anything with a hide faced hammer, then the Mk 6 came along, drinking breathing absorbing AVPIN , started a model aero engine on it once would'nt stop, finally seized up , and was very hot, 20 Sqdn,1956-1959 Oldenburg-Ahlhorn-Gutersloh and of course Sylt-Sylt-Sylt in those days was Engine Fitter

said AKHRASS, skiper752001=yahoo.com, 19.01.2009

Hi freinds, I would like to ask you if you have more photos of the hunter fighter, and most important who still operates the aircraft, military or civilian, and if you know anyone who have spare parts for this great jet fighter. We are still looking for used aircrafts for sale and spares for the existing ones in the Lebanese air force. Please send information if you can and when you can. Thank you.

John Reynolds, jreynolds15=tampabay.rr.com, 29.07.2008

A beautiful aircraft in flight. One you felt like you strapped on your back and became a part of the aircraft. While I was stationed at RAF Lakenheath, the treble one Sga would come over from Water Beach and beat up our air patch about once a month. What a show and it was free. Even the toilet paper they packed in the Speed Brake well.

Robert Scott, buccpilot=yahoo.co.uk, 12.06.2008

This was probably the nicest possible aircraft ever, from a handling point of view, especially without wingtanks or stores. A true pilot's aeroplane!

Philip Oakley, oak135=alltel.net, 27.07.2007

I've always thought this design was perfect mixture of grace and muscle. Thanks for the site, Maksim!
