Couzinet Arc-en-Ciel

The Couzinet 70 Arc-en-Ciel (Rainbow) was a three-engined commercial monoplane designed for the South Atlantic sector of the France-South America route. First flown in 1929, the Arc-en-Ciel was modified in January 1933 and, as the Model 71, began a regular mail run to South America on 28 May 1934. From 24 July that year there was a regular monthly crossing. The Model 70 was derived from an earlier design, the Couzinet 10-01, which was also named Arc-en-Ciel. The Model 70 made a number of record-breaking pioneer flights.


Specification
 CREW4
 ENGINE3 x 650hp Hispano-Suiza 12Nb 12-cylinder V-type liquid-cooled engines
 WEIGHTS
    Take-off weight16790 kg37016 lb
    Payload6001323 lb
 DIMENSIONS
    Wingspan30.00 m98 ft 5 in
    Length16.15 m52 ft 12 in
    Height3.99 m13 ft 1 in
 PERFORMANCE
    Max. speed236 km/h147 mph
    Range6800 km4225 miles
