Latecoere 299
1939
Back to the Virtual Aircraft Museum
  RECONNAISSANCE, BOMBERVirtual Aircraft Museum / France / Latecoere

Latecoere 299

There is no text information for this aircraft at the moment.

Latecoere 299


Specification
 ENGINE1 x 920hp Hispano-Suiza 12 Y-43
 WEIGHTS
    Take-off weight4650 kg10252 lb
    Empty weight3170 kg6989 lb
 DIMENSIONS
    Wingspan15.64 m51 ft 4 in
    Length12.28 m40 ft 3 in
    Height4.46 m15 ft 8 in
    Wing area34.60 m2372.43 sq ft
 PERFORMANCE
    Max. speed345 km/h214 mph
    Cruise speed275 km/h171 mph
    Ceiling6600 m21650 ft
    Range900 km559 miles
 ARMAMENT3 x 7.5mm machine-guns, 900kg of bombs

Comments
bombardier, 23.05.2011

The French equivalent to the Junkers Ju87

courtney, 09.01.2008

Length 12,28 m 12.28 m
Flügelspannweite Wingspan 15,64 m 15.64 m
Flügelfläche Wing area 34,60 m² 34.60 m
Antrieb Drive ein Hispano-Suiza 12Y-43 A Hispano-Suiza 12Y-43
Leistung Performance 686 kW / 920 PS 686 kW / 920 hp
Höchstgeschwindigkeit Maximum speed 355 km/h in 1.500 m Höhe 355 km / h at 1,500 m altitude
Marschgeschwindigkeit Cruising speed 240 km/h in 4.000 m Höhe 240 km / h at 4,000 m altitude
Dienstgipfelhöhe High altitude 6.000 m 6,000 m
Reichweite Reach 1.000 km bei 600 kg Zuladung 1,000 km at 600 kg payload
Leergewicht Dry weight 3.170 kg 3,170 kg
Fluggewicht Flight weight 4.650 kg 4,650 kg
Bewaffnung Armament zwei starre 7,5 mm MG Darne in den Flügeln Two rigid 7.5 mm MG Darne in the wings
Bombenzuladung Bomb load ein 670 kg Torpedo DA oder A 670 kg torpedo DA or
600 kg Bomben 600 kg bombs
Besatzung Crew 3-4
