Nieuport-Delage Ni-D 52

1927

Back to the Virtual Aircraft Museum
  FIGHTERVirtual Aircraft Museum / France / Nieuport

Nieuport-Delage Ni-D 52

There is no text information for this aircraft at the moment.

Nieuport-Delage Ni-D 52

Specification
 MODELNiD-52
 CREW1
 ENGINE1 x 580hp Hispano-Suiza 12Hb
 WEIGHTS
  Take-off weight1800 kg3968 lb
  Empty weight1360 kg2998 lb
 DIMENSIONS
  Wingspan12.00 m39 ft 4 in
  Length7.64 m25 ft 1 in
  Height3.00 m10 ft 10 in
  Wing area27.75 m2298.70 sq ft
 PERFORMANCE
  Max. speed260 km/h162 mph
  Cruise speed226 km/h140 mph
  Ceiling7000 m22950 ft
  Range400 km249 miles
 ARMAMENT2 x 7.7mm

Comments
William, e-mail, 07.12.2023 08:00

The Spanish claimed that their NiD-52s could only reach a speed of 140 m.p.h., not the 160+ . The Republicans claimed that three NiD-52s could pretty well hold their own against one Fiat C.R. 32.

reply

Barry, 12.05.2016 16:41

Based on the earlier Ni-D 42 but with metal replacing the wood of the earlier model, the Ni-D 52 was not ordered by the French with the vast majority of the production going to Spain where it was to fight on both sides in the Civil War. As the war progressed and the Italians and the Germans became involved it was painfully obvious that these machines were outclassed.

reply
