Albatros L.75 Ass
1928
Back to the Virtual Aircraft Museum
  TRAINER, SPORTVirtual Aircraft Museum / Germany / Albatros

Albatros L.75 Ass

Two-seat advanced training biplane powered by a 268kW BMW Va engine.

Albatros L.75 Ass


Specification
 CREW2
 ENGINE1 x BMW VA, 280kW
 WEIGHTS
    Take-off weight1835 kg4046 lb
    Empty weight670 kg1477 lb
 DIMENSIONS
    Wingspan12.5 m41 ft 0 in
    Length10.0 m33 ft 10 in
 PERFORMANCE
    Max. speed208 km/h129 mph
    Cruise speed180 km/h112 mph
    Ceiling5100 m16750 ft
    Range w/max.fuel1950 km1212 miles

Comments
Barry, 04.01.2010

41 models were produced including the prototype. The models were:a,b,c,d,E,F,DSA and DSB.The engines varied with the prototype having a BMW IVa all other models featuring the BMW Va except for the b,F and DSB which used the Junkers L5. Performance for all models was reasonably similar.
