Lavochkin La-11

Evolved from the La-9 to meet a requirement for a fighter with sufficient range to fulfil the escort role, the La-11 was destined to be the last piston-engine fighter from the Lavochkin bureau. It had a wing fundamentally similar to that of the La-9 and retained the ASh-82FN engine, but provision was made to attach auxiliary fuel tanks at the wingtips, the ventral oil cooler was incorporated in the engine cowling and armament was reduced to three 23mm NS-23 cannon. The first prototype was flown in June 1947 under the design bureau designation La-134, and production (1947-51) at Gor'kiy was to total 1,182 aircraft.

The La-11 was supplied in some numbers to both the Chinese and the North Korean air forces, and saw operational use during the Korean conflict. It was finally phased out of first line VVS service in the early 'fifties.

Lavochkin La-11

Specification
 WEIGHTS
  Take-off weight3990 kg8796 lb
  Empty weight2770 kg6107 lb
 DIMENSIONS
  Wingspan9.8 m32 ft 2 in
  Length8.7 m29 ft 7 in
 PERFORMANCE
  Max. speed674 km/h419 mph
  Ceiling10250 m33650 ft
  Range w/max.fuel2550 km1585 miles

3-View
Lavochkin La-11A three-view drawing (1690 x 1240)
