Lisunov Li-2
1939
Back to the Virtual Aircraft Museum
  PASSENGER, TRANSPORTVirtual Aircraft Museum / USSR / Russia / Lisunov

Lisunov Li-2

Russian licence-built version of the Douglas DC-3, originally powered by 671kW Shvetsov M-62 radials in the PS-84 first version, but later fitted with uprated Shvetsov ASh-62 radials; production comprised a number of variants, some of them armed with turreted armament; the Li-2G freighter, Li-2P personnel transport, Li-2PG convertible model and the Li-2V high-altitude model are best known of the variants.

Lisunov Li-2


Specification
 CREW4
 PASSENGERS14-24
 ENGINE2 x ASh-62IR, 735kW
 WEIGHTS
    Take-off weight10700 kg23590 lb
    Empty weight7700 kg16976 lb
 DIMENSIONS
    Wingspan28.8 m95 ft 6 in
    Length19.7 m65 ft 8 in
    Height5.2 m17 ft 1 in
    Wing area91.7 m2987.05 sq ft
 PERFORMANCE
    Max. speed320 km/h199 mph
    Cruise speed220 km/h137 mph
    Ceiling5600 m18350 ft
    Range w/max.fuel2200 km1367 miles
    Range w/max.payload1200 km746 miles
