Petlyakov Pe-8 / Tupolev ANT-42 / TB-7

The first prototype flew on 27 December 1936. Production Pe-8 were well armed, carrying two 7.62mm machine-guns in a spherical nose turret, two machine-guns or a 20mm cannon in a dorsal turret, one hand-operated 12.7mm machine-gun in the rear of each inboard engine nacelle under the wing trailing edge and a 20mm cannon in a tail turret, plus up to 4,000kg of bombs stowed internally.

Initially the Pe-8 was powered by four 820kW M-105 engines and entered service in this form in 1940. The 1941 model had 1,080.5kW Mikulin AM-35A fitted. During the production run (which lasted until 1944) several other engines were installed either experimentally or as a standard type, including the 967kW AM-38, 1,304kW M-82 and a diesel engine.

On the night of 21 July 1941 German bombers attacked Moscow for the first time. As a reprisal Soviet IL-4 bombers made their first attack on Berlin on the night of 7 August. The resulting damage was minimal but it cleared the way for further attacks. In the spring of 1942 the Soviet ADD or Long-Range Aviation was formed, using the Pe-8 as its main component. Pe-8 raids on Germany began in July 1942 with small numbers of aircraft attacking Konigsberg and then Berlin and elsewhere. However these were not very successful and extremely heavy losses were endured. Although Pe-8 remained operational as bombers until the end of the war, a number were converted into transports.

Petlyakov Pe-8 / Tupolev ANT-42 / TB-7


Specification
 CREW8-12
 ENGINE4 x AM-35A, 880kW
 WEIGHTS
    Take-off weight32000 kg70548 lb
    Empty weight18000 kg39683 lb
 DIMENSIONS
    Wingspan39.1 m128 ft 3 in
    Length23.6 m77 ft 5 in
    Wing area188.7 m22031.15 sq ft
 PERFORMANCE
    Max. speed440 km/h273 mph
    Cruise speed340 km/h211 mph
    Ceiling11000 m36100 ft
    Range w/max.fuel6000 km3728 miles
    Range w/max.payload3000 km1864 miles
 ARMAMENT2 x 20mm machine-guns, 4 machine-guns, 2000-4000kg of bombs

Petlyakov Pe-8 / Tupolev ANT-42 / TB-7

Comments
Barry, 06.02.2013

With the final models powered by radial engines the Pe8 was capable of carrying a maximum bomb load of in excess of 11,000lb and was capable of flying as high as 36,000 ft.
Agreed at height it was faster than some German fighters like the Bf109B, but let's face it how many 'B' models were used in the defence of the "Fatherland", and I do not think it was such a contender to later Me109s and more importantly the Fw190. The range was good and it's bomb load was better than the B17 but short of a Lancaster. However, as already noted Uncle Joe did not have much of a view on strategic bombing!

bombardier, 2888617=gmail.com, 23.05.2011

This aircraft was one of the best 4 engine bombers of the War

Pintér András, pinterandras=vipmail.hu, 26.01.2011

Diesel was Csaromkij Acs-30(in hungarian orthograph), Charomky Ach-30 (english)

Sturm, 31.05.2010

Always been one of my favorite (and relatively unknown) heavies.

Leo Rudnicki, leo_rudnicki=hotmail.com, 22.06.2009

The engines originally proposed were AM34's with the blower engine in the fuselage. Trouble with the engines resulted in Petlyakov's stay in "desiner's prison". Losses were heavy when bombing German targets so it's hard to belive Molotov would go. Papa Joe himself never flew. Ever. Too scared. Too easy to rig a crash and too many Nazi and capitalist swine pig-dogs willing to do it.

Gary Van Horn, grvanhorn=mail.manti.com, 26.04.2009

The original design of the TB-7 (it was ne-named Pe-8 after the designer's death)included a fifth engine that was used to feed on-board air to itself and the other four engines to allow the bomber to fly at altitudes greater than could be reache by any fighter of that time.

Tommy, thomas.rey=vtg.admin.ch, 21.04.2009

Were the outer engines cooled by the combined radiators in the inner nacelles?

starwarsfan, starwarsfan=vipmail.hu, 23.01.2009

I've just seen a documentary with an ex Soviet spy named Suworov (an author of several "new line" books on the Soviet strategy during and before the ww2). He stated that Molotov flew over the Third Reich two times with a TB-7 without any sign of fear beeing shot during the flight (well, he could get used to death so close to Stalin). According to Suworov the TB-7 was an unparallel wonder - it flew higher than the Flaks could shoot and was faster than the German fighters. Do you know anything about these flights?

Nick goth, Goth.nick=yahoo.co.uk, 08.01.2009

Gud rear defence wif tail,top+rear engine guns.any figther attaks reppeld wif such armament?any fighters shot down?no gun undaneath the belly?when,where was 5,000kg bomb droppd?a gud plane reminds me of b17 or italian piaggio p108.

Josh, Joshua4844=hotmail.com, 16.12.2008

are any Petlyakow Pe-8 left?

Pascal, fks.pk=cegetel.net, 07.10.2008

From which material the Pe 8 was made of?

Norbert, 04.03.2008

The gunners get in over a little door at overside of the wing direcly over the gun post.

Victor, bankrobber70=yahoo.com, 03.02.2008

How did the gunners get into the gun post at the engine? Did they have to stay there the whole flight?

Aleksandr, alex_04_57=yahoo.com, 21.12.2006

What was ceiling with max payload (4000 kg of bombs)?
