Sukhoi UTB-2

The UTB-2 was a trainer derivative of the Tu-2. The UTB-2 was structurally similar, but because of the elimination of combat equipment it was much lighter, and this allowed the use of less powerful engines. The front fuselage was widened to make room for a trainee and instructor side-by-side.

Sukhoi UTB-2


Specification
 CREW3
 ENGINE2 x ASh-21, 515kW
 WEIGHTS
    Take-off weight6546 kg14432 lb
 DIMENSIONS
    Wingspan18.9 m62 ft 0 in
    Length14.0 m46 ft 11 in
    Height4.8 m16 ft 9 in
    Wing area48.8 m2525.28 sq ft
 PERFORMANCE
    Max. speed380 km/h236 mph
    Cruise speed340 km/h211 mph
    Ceiling6000 m19700 ft
 ARMAMENT1 x 12.7mm machine-guns, bombs
