Tupolev Tu-134

Known originally as the Tu-124A, this aircraft is a rear-engined twin-turbofan development of the Tu-124. It had completed more than 100 test flights when first details and photographs were released in mid-September 1964. The prototype was followed by five preproduction aircraft and the Tu-134 then went into series production at Kharkov. It entered international service on Aeroflot's Moscow-Stockholm route in September 1967, after a period on internal services, and was joined by the `stretched' Tu-134A in the Autumn of 1970. Production ceased in 1985 after 852 had been built.

Tupolev Tu-134


Specification
 MODELTu-134A
 CREW3
 PASSENGERS64-80
 ENGINE2 x Soloviev D-30-II turbofans, 30.26kN
 WEIGHTS
    Take-off weight47000 kg103618 lb
    Empty weight29050 kg64045 lb
 DIMENSIONS
    Wingspan29.0 m95 ft 2 in
    Length37.05 m122 ft 7 in
    Wing area127.3 m21370.24 sq ft
 PERFORMANCE
    Max. speed885 km/h550 mph
    Ceiling11890 m39000 ft
    Range w/max.payload1890 km1174 miles
