Yakovlev Ya-6 (AIR-6)
1931
Back to the Virtual Aircraft Museum
  PASSENGERVirtual Aircraft Museum / USSR / Russia / Yakovlev

Yakovlev Ya-6 (AIR-6)

AIR-5 adaptation for domestic M-11 engine. It was ready in May 1932, flew on September 8 and passed all trials easily. Adopted as short range liaison aircraft.

In 1934 group of AIR-6 performed flight Moscow-Irkutsk-Moscow (with refuel landings), covering more than 10,000km.

During 1934-36 total 486 AIR-6 were built. Twenty of them were modified as ambulance with room for a stretcher and doctor.

Yakovlev Ya-6 (AIR-6)


Specification
 CREW1
 PASSENGERS2
 ENGINE1 x M-11, 81kW
 WEIGHTS
    Take-off weight993 kg2189 lb
    Empty weight620 kg1367 lb
 DIMENSIONS
    Wingspan12.1 m40 ft 8 in
    Length8.0 m26 ft 3 in
    Height2.3 m8 ft 7 in
    Wing area19.8 m2213.13 sq ft
 PERFORMANCE
    Max. speed166 km/h103 mph
    Cruise speed140 km/h87 mph
    Ceiling4500 m14750 ft
    Range650 km404 miles
