Yakovlev AIR-20 / UT-2 - sport, training

Yakovlev AIR-20 / UT-2
1935

Back to the Virtual Aircraft Museum


SPORT, TRAINING	Virtual Aircraft Museum / USSR / Russia / Yakovlev

Yakovlev AIR-20 / UT-2

Two-seat monoplane trainer, developed from AIR-10. 7243 built. Ya-20 was a version with 120hp Renault engine.

Yakovlev AIR-20 / UT-2

Specification

CREW	1
PASSENGERS	1
ENGINE	1 x M-11, 74kW
WEIGHTS
Take-off weight	856 kg	1887 lb
Empty weight	616 kg	1358 lb
DIMENSIONS
Wingspan	10.2 m	33 ft 6 in
Length	7.0 m	22 ft 12 in
Height	3.0 m	9 ft 10 in
Wing area	17.1 m²	184.06 sq ft
PERFORMANCE
Max. speed	200 km/h	124 mph
Cruise speed	160 km/h	99 mph
Ceiling	32000 m	105000 ft
Range	750 km	466 miles
