Fairchild C-123 Provider

The C-123 troop and cargo transport was designed by the original Chase Aircraft Company. A production order for 300 C-123B, held by the Kaiser-Frazer Corporation (which had acquired a majority interest in the Chase company in 1953), was cancelled in June 1953. New bids were asked for, as a result of which production of the C-123B was assigned to Fairchild. The first Fairchild-built C-123B flew on 1 September 1954 and production aircraft entered service with the USAF's 309th Troop Carrier Group in July 1955. Orders totalling more than 300 aircraft were completed by mid-1958, six going to Saudi Arabia and 18 to Venezuela.

In 1955 the prototype C-123B was fitted experimentally with two Fairchild J44 turbojet engines mounted at the wingtips to provide auxiliary power for use in an emergency. As a result ten production aircraft were modified into C-123J with turbojet engines fitted. Meanwhile a small number of C-123H had been produced with wide-track landing gears.

The prototype YC-123H was later experimentally fitted with CJ610 auxiliary turbojet engines and flown on 30 July 1962. Having been tested in South Vietnam as a counter-insurgency aircraft, 183 more C-123B were given 12.68kN General Electric J85-GE-17 auxiliary turbojet engines in underwing pods and designated C-123K. Some were further converted to AC-123K Spectre gunships for service during the Vietnam conflict.

Fairchild C-123 Provider

Specification
 CREW2
 ENGINE2 x P+W R-2800-99W, 1840kW
 WEIGHTS
  Take-off weight27240 kg60054 lb
  Empty weight14100 kg31085 lb
 DIMENSIONS
  Wingspan33.6 m110 ft 3 in
  Length23.3 m76 ft 5 in
  Height10.4 m34 ft 1 in
  Wing area113.6 m21222.78 sq ft
 PERFORMANCE
  Max. speed392 km/h244 mph
  Ceiling7000 m22950 ft
  Range w/max.fuel2350 km1460 miles

Comments1-20 21-40 41-60 61-80 81-100 101-120
nick, e-mail, 05.05.2012 02:45

Hi everyone, i love the Provider. Bit of an old world /new world bird with rear ramp and underwing jets and big prop engines. Now i do wonder, the 3 types of underwing jets in the article above would boost speed i assume. do we know how each jet engine pairs would make the Provider perform? would CJ610 jets be better than 44 or 85s? or does the extra fuel burn make it a mute point? and do the 3 types of jet engines burn the same fuel as the props?? confusing but very interesting. hope you can give info. also, if the jets were underwing, if used enough times in flight hours, would the jets create extra strain on the wing spars? i heard that Avro Shacketons were given jets in the outer engine nacelles but had them removed due to extra stress. well... the B-50 Washington had jets in the outer nacelles and 4 props so hw did fatigue bother that bird? very confusing. need a good heads up from an airplane info person... thanx all:) nick.

reply

Carol, e-mail, 21.03.2012 21:30

Can you tell me if the C-123's ever landed aboard aircraft carriers, specially the USS Kitty Hawk? Also, can you tell me what type of planes were used in dropping Agent Orange.

reply

Pamela, e-mail, 06.08.2021 Carol

We’re looking for this same information as you were. Did you ever find out if the C-123 landed on the USS Kitty Hawk? My husband was on the crash crew in 1969-70.

reply

Al, 14.03.2021 Carol

We tried! landing lights on, gear down, flaps down. They were going crazy on the flight deck. Red lights wave offs radio warnings. Didn't really want to do it we were just dorking around we went on to land at Can ron bay on a psp runway

reply

Jon Christie, e-mail, 12.02.2012 15:47

What memories reading over the emails from past C123 personnel. I worked those great birds from 1970 to 1973. Spent tour in Nam with them. I was at Phang Rang when the 123 nosed into Cam Ron Bay from the broken wing flap bracket. Several of us helped pull all the brackets off and replaced them with "checked /certified" brackets. Being a part of the 311 TAS was super. At Hurlburt we did missions from spraying south of Brownsville, TX to carring serile flies to Porta Rico. Spent many hours working that old Horse, but always maintained with excellence. Many crew members are retired around Hurlburt Fld area.

reply

sidebar, e-mail, 05.02.2012 12:22

the C123 That sprayed herbicide was a UC123B-K model there were very few of these built and were used by the Ranch Hand Squadron the 12th SOS,you could see the spray booms on wings and at the rear behind the cargo door,no booms it wasn't a spray bird

reply

Joe, e-mail, 13.01.2012 13:46

What is the maximum amount of fuel carried by a C-123 Provider?

reply

Ron Stowell, Msgt USAF (Ret), e-mail, 11.01.2012 02:29

Hey guys, Need your help. C-123s at Udorn 1970 - 1970. Flying spray missions from there. VA says there herbicides stored there, but if you had a C-123 ready for a mission seems to this old T-28 crew chief that the mixed herbicide were already on board. Would that not be "stored on the base" until use? A couple of sworn testimonies from pilots or crew would greatly help an herbicides /AO claim.Det 1, 56 Udorn. Thanks to all for your sacrifice and service.

reply

Ryan, e-mail, 10.01.2012 11:34

I believe there is one at chino airport, it has not been up in maybe ten years but it is all intact and everything works on it, I talked to the owner of it and there is plans soon for it to fly

reply

Ryan, e-mail, 10.01.2012 11:34

I believe there is one at chino airport, it has not been up in maybe ten years but it is all intact and everything works on it, I talked to the owner of it and there is plans soon for it to fly

reply

bob rudd, e-mail, 08.10.2011 01:20

Correction? If i'm not mistaken the reunion is Oct 10-14.Hope i'm not there alone. :)

reply

Frank Gerstenkorn, e-mail, 04.10.2011 06:06

I was and flight engineer (really, a MAC guy from C141As) on Bookies with the 310th at Phan Rang from September 1969 to October 1970. In nearly 950 hrs of flight and some 1300+ takeoffs and landing the Provider never let me down. There is a C123s in SEA reunion in Branson Mo next week (Oct 13-15 and there's time to register via C123sinsoutheastasia.org. To Tom Griffing, I flew every tail number in your post. Thanks for all your hard word keeping my tail in the ail on great airplanes.

reply

Pete Sims, e-mail, 21.08.2011 07:44

Ernie Colby: We carried conex containers from time to time while I was in Nam. I'm not sure of the size though. It was a pickle loading them, they had to be nursed up /in /down /in just to get them inside the cargo bay. There was no way to jettison them if you had an emergency. Hope that helps.

reply

Ernie Colby, e-mail, 05.08.2011 02:54

Does anyone know if a standard 8 x 20 shipping container would fit in the back of a c123?

reply

Gary Woodruff, e-mail, 19.07.2011 20:10

I flew C-123 in 1965-66 in 310th ACS at Saigon and then Nha Trang, then went to England AFB LA. until April 1967. I then separated from the active duty. We had many rich experiences in the airplane.

reply

James Mayfield, e-mail, 17.05.2011 02:35

Mr. Tucson, not sure how to get in touch...let me know if you figured out what to do with yours. 203.921.21644

reply

John Mulvey, e-mail, 01.05.2011 17:59

If anyone has any ideas of what could be done with C-123K these days, I would very much like to get in contact with you.
We have an ex-DoS ship 54-0659 that was used in Peru until 1992 and then retired.
Our ship (now) N123JK is sitting in Tucson and hoping to fly a little longer.
We have parts, books, tooling, etc. I want to install new hoses, overhaul the carbs and props before we fly it out.
I look forward to speaking to any one interested.

reply

michael, e-mail, 07.04.2011 03:08

I was Ubon AB thailand in 1969 TDY for 90 days. blackspot which were c123s any have any pictures of the bomb shed and the supply shed there and does any one remember if any of the 2 c123s were ever used for spraying agent orange.

reply

Virgil Farling, e-mail, 01.04.2011 15:43

I was a crew cheif on the C-123 black birds of the First Flight detachment in Nha Trang in 1968-69. They really were a work horse type aircraft whose most re-occurring problems were related to engine oil leaks and hydraulic issues. The APUs also required a lot of attention. That said they were an excellent dependable aircraft for the mission they had.

reply

Roger, e-mail, 31.03.2011 19:16

only thing i would like to say is i was At Katum on a 105 howizer for nine months during 1968-1969 and i know they got fired on and could not stop to unload or pick up sometimes.

reply

Glen Houpt, e-mail, 29.03.2011 03:45

I am a volunteer in our new Air Museum here in Sioux City Iowa.
We have a C-123K We are working on for viewing only. Some cockpit instruments are missing. Are there any photos available of the Cockpit Instruments. WE have some old instruments from other planes that may work. Please send any photos of the instruments you have available. Thanks much.
Glen Houpt
Sioux City
Iowa glenhoupt2nd@aol.com.

reply

Ray C Ingram, e-mail, 24.03.2011 03:34

My first loadmaster duties at Pope were aboard the 123 in 1962. Did the Vietnam tour as "advisor" several times with the last one as loadmaster on the C-130 in 1965 out of Dyess /Phillippines.
Both Very reliable machines, the 123 took all kinds of bullet holes without any problems. Even got to fly a little :)

reply
