Albatros B I/B II

The Albatros B.I and smaller B.II were developed before the outbreak of war in 1914 and were roughly equivalent to the British Royal Aircraft Factory B.E.2, although slower but better looking. Layout was fairly conventional for the time with the pilot occupying the rear cockpit and the observer the front. No armament was provided as aerial combat was a thing of the future. Power was provided by a 74.5kW Mercedes D.I or an 82kW Benz Bz.II engine and an ugly exhaust manifold partially obstructed the forward view. However, they were strongly constructed and well liked by their crews and were widely used for reconnaissance duties during the first year of the war on both Western and Eastern Fronts.

Manufacture was undertaken by several companies. A seaplane version was also built in small numbers and a few B.II were operated by Austro-Hungary. In 1917 the B.II was ordered back into service as the B.IIa dual-control trainer, powered by an 89.4kW Mercedes D.II or Argus As.II engine.

Albatros B I/B II

Specification
 CREW2
 ENGINE1 x Mc, 74kW
 WEIGHTS
  Take-off weight800 kg1764 lb
  Empty weight600 kg1323 lb
 DIMENSIONS
  Wingspan14.3 m47 ft 11 in
  Length8.6 m28 ft 3 in
  Height3.5 m12 ft 6 in
  Wing area43.0 m2462.85 sq ft
 PERFORMANCE
  Max. speed100 km/h62 mph
  Ceiling3000 m9850 ft
  Range w/max.fuel650 km404 miles

Comments
Billy R Leon, e-mail, 21.09.2021 19:14

I came across a figure of 42 Albatros B.II machines built. Does anybody else know of different figures?

reply

William R. Leon, e-mail, 22.02.2018 21:23

Further digging has brought to light that the Albatros B.I's in Austro-Hungarian service are in all actuality Albatros C.I's and C.III's built by Austria-Hungary and named B.I. Confusing....actual #'s of B.I's built seems to be elusive, although I did find reference to a peak strength of 157 machines in April 1915. Given a loss rate of 20% due to shoot downs, crashes, and write-offs, and then including the 20 Turkish and 2 Bulgarian examples would give us a ballpark figure of somewhere around 210 machines. But this figure too should be taken with a grain of salt since the Turkish and Bulgarian machines could have been German machines originally and given to those two countries when the "C" types started to come online.

reply

William R. Leon, e-mail, 06.02.2018 17:59

I am looking for the production figures for both the B.I and B.II. I have some data on the B.I in other Central Powers air corps. I have 204 examples serving with Austria-Hungary through 1915. 20 examples served with the Turkish Flying Corps from 1915 until the end of the war. Bulgaria seemed to operate two machines throughout 1915.

reply

lxbfYeaa, e-mail, 14.03.2024 William R. Leon

20

reply

David Cleaver, e-mail, 12.01.2011 22:33

My Grandfather wounded the pilot, and forced down a Albatros B-III type, I have several pictures showing the plane in good condition, plus I have the propeller, wonder if the plane is sitting in a museum someplace?

reply

Dennis Morris, e-mail, 11.07.2009 23:24

My wife's grandfather flew the BII during WW1. I have a photograph of him standing under the propeller along with his "Beobachtungs Schule" students.

reply
