Savoia-Marchetti S.M.82 Canguro

The S.M.82 of 1938 was a development of the S.M.75, from which it differed by having a deeper fuselage, greater loaded weight, redesigned fin and rudder, and the addition of a hydraulically operated retractable gun turret on top of the fuselage to the rear of the pilot's cockpit. Initially powered by three 633kW Alfa Romeo 128 engines, it could accommodate up to 40 fully armed troops or be used as a long-range heavy bomber. It was widely used by the Regia Aeronautica and some were operated by the Luftwaffe from 1943.

Savoia-Marchetti S.M.82 Canguro

Specification
 CREW5-6
 ENGINE3 x Alfa Romeo 128 RC.21, 708kW
 WEIGHTS
  Take-off weight18020 kg39728 lb
  Loaded weight10550 kg23259 lb
 DIMENSIONS
  Wingspan29.68 m97 ft 5 in
  Length22.9 m75 ft 2 in
  Height6.0 m20 ft 8 in
  Wing area118.6 m21276.60 sq ft
 PERFORMANCE
  Max. speed370 km/h230 mph
  Ceiling6000 m19700 ft
  Range3000 km1864 miles
 ARMAMENT1 x 12.7mm machine-guns, 4 x 7.7mm machine-guns, 4000kg of bombs

3-View
Savoia-Marchetti S.M.82 CanguroA three-view drawing (614 x 800)

Comments
lxbfYeaa, e-mail, 14.03.2024 06:38

20

reply

Ben Beekman, e-mail, 06.03.2011 22:41

This was quite an outstanding aircraft for its day. Even the Luftwaffe could see it was better than their own Ju.52 as a transport. It was vulnerable to attack due to its low ceiling and lack of adequate defensive armament. In 1942, one of these aircraft flew from Rome to Tokyo taking 4 days each way to fly the distance of 16,200 total miles.

reply

Matteo, e-mail, 10.02.2011 03:00

Disastrous Bomber? It was not that disaster. Some Sm.82 performed the longest range bombing mission of the entire WW2. They took off from Rodi(Rhodos,now Greece) bombed a refinery in Bahrein and then landed in Eritrea.
But being originally designed as a transport and the project was emergency converted (being the war approaching) into a bomber it was a better transport but still a decent bomber, probably better than it was reasonable to expect.
I have no confirmed sources(and sounds me really strange) but I heard that only transport units were equipped with it, giving them also bombing capabilities.
Anyway i confirm that some planes were adapted for 3 special transport roles to transport disassembled complete Cr.42 fighters, L3 light-tanks /tankette, and spare engines to the Italian Eastern Africa (A.O.I.). Apart being heavy and bulky, consider also that the route was long(too long for a fighter transfer flight), much in unsafe /unfriendly skyes and with limited chance of refuelling since AOI was under "siege" by sea and land.
These solutions and the adventures of this Units are told by an interesting book "S.A.S. servizi aerei speciali della Regia Aeronautica(Special Air Services of the Royal Italian Air Force)- Massimo Civoli"

reply

AvComps, e-mail, 21.10.2009 19:02

After some lengthy research into the topic of A /C used in S.A., I have an qustion about the 4 similar machine made an used by S.M.-1938-1941. The subject of pontoon affixing is in involved. One of the 4 machines did appear on floats, The SM-87, as seen in Jane's 1938-39 vol. I think the SM-82 may also have appeared in the floatplane configuration with in the same time frame. The five which left the region are the ones in question. Please contact, if there is data about the SM-82 on floats.

reply

Sgt.KAR98, 03.07.2008 04:33

This plane is somewhat scary,dunno why.

reply

3VI, e-mail, 22.02.2008 22:40

Yes. It could carry a complete CR.42 or G.50 or MC.200 fighter inside. About 30 planes were in charge after WWII and until the end of '50s as transport (46a Brigata Aerea Trasporti) powered by 3 P.W. Twin Wasp engines.
About power, you must consider that SM.75 had the same power of previous SM.81 carrying double payload. So, the SM.82 (derived from SM.75) with a little more power made the miracle!

reply

TKerr, e-mail, 15.09.2007 18:02

I read somewhere that this beast could cary a dismantled fighter plane! What...fueselage + wings? If true, it should have been a champion transport though a disastrous bomber. The take-off weight seems high for the engine power. Is there any information on numbers produced and operational roles?

reply
