Bristol Badminton
1926
Back to the Virtual Aircraft Museum
  Virtual Aircraft Museum / United Kingdom / Bristol

Bristol Badminton

There is no text information for this aircraft at the moment.

3-View
Bristol BadmintonA three-view drawing (800 x 683)


Specification
 CREW1
 ENGINE1 x 510hp Bristol Jupiter VI
 WEIGHTS
    Take-off weight1121 kg2471 lb
    Empty weight804 kg1773 lb
 DIMENSIONS
    Wingspan7.34 m24 ft 1 in
    Length6.45 m21 ft 2 in
    Height2.79 m9 ft 2 in
    Wing area19.51 m2210.00 sq ft
 PERFORMANCE
    Max. speed258 km/h160 mph

Comments
Barry, 20.06.2016

Frank Barnwell designed racing bi-plane, which was entered in the 1926 Kings Cup Air Race but had to retire with a fuel feed problem. In 1927 it was rebuilt using a revised wing and interplane struts with a raised cockpit as in the 3 view drawing. It gained a C of A 26th July 1926 but fatally crashed two days later.
