Yakovlev Yak-12

1949

Back to the Virtual Aircraft Museum
  UTILITYVirtual Aircraft Museum / USSR / Russia / Yakovlev

Yakovlev Yak-12

The Yak-12 was a single 179kW AI-14R-engined high-wing light general-purpose aircraft built in several versions from the late 1940s. It was known to NATO as Creek.

Yakovlev Yak-12

Specification
 CREW1
 PASSENGERS1
 ENGINE1 x AI-14R, 190kW
 WEIGHTS
  Take-off weight1435 kg3164 lb
  Empty weight1014 kg2235 lb
 DIMENSIONS
  Wingspan12.6 m41 ft 4 in
  Length9.0 m30 ft 6 in
  Height3.1 m10 ft 2 in
  Wing area2.9 m231.22 sq ft
 PERFORMANCE
  Max. speed220 km/h137 mph
  Cruise speed160 km/h99 mph
  Ceiling4600 m15100 ft
  Range w/max.fuel760 km472 miles
