Yakovlev Yak-26

1955

Back to the Virtual Aircraft Museum
  BOMBER, RECONNAISSANCE AIRCRAFTVirtual Aircraft Museum / USSR / Russia / Yakovlev

Yakovlev Yak-26

There is no text information for this aircraft at the moment.

Yakovlev Yak-26

Specification
 WEIGHTS
  Take-off weight11500 kg25353 lb
  Empty weight7295 kg16083 lb
 DIMENSIONS
  Wingspan11.0 m36 ft 1 in
  Length20.15 m66 ft 1 in
 PERFORMANCE
  Max. speed1400 km/h870 mph
  Ceiling15100 m49550 ft
  Range2050 km1274 miles

Comments
Erdös Andrés, e-mail, 25.11.2013 20:12

The Yakovlev Yak-26 was a tactical supersonic bomber version of the Soviet Yakovlev Yak-27 (NATO reporting name 'Flashlight') developed in 1956.
The Yak-26 was developed from the Yak-25, along with the Yak-27 family of interceptor fighter and reconnaissance aircraft. The main goal was to increase the speed to supersonic. Although it kept the Yak-25's layout, it had a more streamlined and longer fuselage with a glazed nose for a navigator /bombardier, replacing the Yak-25's radome, modified wings and stronger engines. The Nudelman N-37 cannon was replaced with four NR-23 23 mm weapons (two in the tail), and an internal weapons bay was added for 1,000 kg (2,205 lb) of bombs, including the nuclear bomb Tatyana. Additional bombs could be carried on underwing pylons.
Although flown at the Tushino air show on 24 June 1956, only ten were produced, and the type did not enter service.

reply

bombardier, e-mail, 24.05.2011 11:03

Bomber derivative of the Yak-25

reply
