Boeing XPBB-1 Sea Ranger

In 1940 the solution to German U-boats off the US east coast was deemed to be giant long-range flying-boat bombers. Boeing was the obvious builder with its track record of the prewar "Clipper" airliners and the Navy ordered 57 to start with. Boeing built a whole new plant at Renton by Lake Washington to build the Sea Ranger. The XPBB-1 prototype flew in July 1942 and was the largest twin-engined aircraft built to date, but the experiences of the Pacific War saw the War Department completely revise its strategy in favour of land-based bombers. The Sea Ranger programme was cancelled and the Renton plant was swapped with the army for one in Kansas. Renton subsequently built over 1000 B-29s and later C-135 jet tanker/transports and 707 airliners. The solitary Sea Ranger never flew a combat mission before it was mothballed and scrapped.

Jim Winchester "The World's Worst Aircraft", 2005

Boeing XPBB-1 Sea Ranger


Specification
 CREW10
 ENGINE2 x 2300hp Wright R-3350-8 piston engines
 WEIGHTS
    Take-off weight45872 kg101131 lb
 DIMENSIONS
    Wingspan42.58 m140 ft 8 in
    Length28.88 m95 ft 9 in
    Height10.40 m34 ft 1 in
 PERFORMANCE
    Max. speed348 km/h216 mph

3-View
Boeing XPBB-1 Sea RangerA three-view drawing (800 x 361)

Boeing XPBB-1 Sea Ranger

Comments
Klaatu83, 05.02.2016

Only one of these was ever built so, inevitably, it became known as "The Lone Ranger". There were several reasons for that. First, the Navy decided they didn't need a flying boat bomber in this catagory after all. Second, Boeing's facilities, and their Renton, Washington plant in particular, were required for the B-29 development program. Third, the Wright R-3350 engines, which powered the Sea Ranger, were also required for the B-29, which took priority.

Michael Moore, 10.04.2015

Correction on previous e-mail. Should be Crew Chief while serving in the Strategic Air Command, 1955 to 1963.

Michael Moore, 10.04.2015

Beautiful aircraft. If possible I would like to have a picture of the two shown on this page. 10 x 8 or 7 x 5. I will pay for the cost. I am very familar with Boeing aircraft. I was a chief on the B-47E and KC-135. Kind Regards, Michael

Joshua Crooker, 07.03.2014

By the way, I could also use some information on the PB2Y, thanks.

Joshua Crooker, 07.03.2014

If any of you think you may be able to obtain, or can tell me how to obtain full scale blueprints for this aircraft, please let me know. I am looking to build a full scale, airworthy reproduction, or replica of this aircraft. I plan on eventually building a fleet, to be used on UNICEF missions, or something similar. If you have any info, please email me here: j.crooker20@gmail.com. Thanks.

Rob Milford, 02.12.2010

Bob Robbins was the prime test co-pilot for this a/c, told me many times of the Navy delivery flight. The Navy Captain came in, Bob told him to sit in the left seat, and he flew from there, since Bob didn't have any left seat time! Bob allowed that there was one ofther issue: This used the same engine as a B-29, and the big bird needed 'em more. And, it ended up being called the "Lone Ranger" since it was 'one of as kind'. Never saw the color pic above..very nice!

steve, 28.11.2008

With a max range of 6300 miles @ 158 mph, a incredible flight duration of nearly 40hrs, was this potentially the longest flight duration of a standard production aircraft, a world record possibly

Jim Medley, 27.05.2008

This plane looks a lot like a USN ASW plane flown by VP 49 out of Burmuda during Cuban crises. It was called the P5M Marlin. If you have info please email to jmedley1341@msn.com

Cass Phillips, 26.04.2008

The hull of this plane looks a lot like the PBM.

Do you have any comments about this aircraft ?

Name    E-mail


COMPANY
PROFILE


FACTS AND FIGURES

Surprisingly for such a large flying boat, the XPBB was twin-engined. Defensive armament was only four machine guns but the bomb load was greater than a B-29's.

The XPBB-1 s wing was based on that of the B-29 Superfortress. Some of rhe aerodynamics were inherited from Boeing's Model 314 Clipper.

There was a plan to use special barges to catapult launch the Sea Ranger so as to increase the already long range, but this was never tested.
